Hot selling DL-76/60 Flip chip US Bridgelux 30w 50w cob led chip Used for Ceiling Lamp & Down lamp CE ROHS LM-80
Product Description
| Produce Name | DL-76/60 Led cob chip |
| Watts | 40w |
| Current | 1200mA |
| Voltage | 30-32v |
| CRI | 70 / 80 |
| Color Temperature | 2700k - 6500K |
| Lumens | 110-120lm/W |
| Chip Brand | US Bridgelux |
| Warranty | 3 Years |
Specification
◆Mechanical Dimensions: R76.0x2.2(mm)
◆Package Structure:Aluminium Base
◆CRI(Ra):Min.70 / 80
◆Nominal CCT: 2700k, 3000k, 4000k, 6000k
◆Chromaticity Range: 3-step MacAdam Ellipse
◆RoHS CE compliant
◆Better die arrangement for optics
◆Wide range of luminous fluxand high efficacy
Product Feature
This series of products is encapsulated by LED flip-chip technology.
1.It get rid of the gold thread, enhance the anti-pressure characteristics of the light source, and strengthen the reliability of the product.
2. The LED chip is packaged directly on the substrate layer, eliminating the solid crystals, and the heat generated by the chip can be passed quickly through the substrate layer.
3. High reliability, can be used in high temperature, low temperature, high humidity, etc.
Electro Optical Characteristics
| Product Code | Nominal CCT | CRI(Ra) | Luminous Flux(lm) | Efficacy ( lm/W ) | Forward Current (mA) | Voltage (V) |
| | | Ra | R9 | | | | |
| | | Min. | Min. | Min. | Typ. | Typ. | | Min. | Typ. | Max. |
| XC7660-M1008-A3080-E33 | 3000K | 80 | 0 | 4400 | 4900 | 110-120 | 1200 | 30 | 30.5 | 31 |
Company Information
Company introduction
SHENZHEN XUANCAI ELECTRONIC Co.,Ltd is a comprehensive LED lighting company, which is integrating LED light source packaging, optical design, and development , headquartered in Shenzhen, China, with more than 10 years experience in packaging high-end LEDS. Our company have the most advanced COB packaging production line, rich COB product line, color temperature range from 1700K-20000K, color rendering index RA70, RA80, RA90, RA95, RA98, etc. Power can range from 3W-500W single COB light source, double color temperature dimming system, etc., can meet the light source requirements of different customers in different occasions, provide customers with personalized design, customization, also provide customers with better visual effects.
company management idea:
1.to create wealth for customers
2.to create the future for the staff
3.for the enterprise to create profits
4.to create value for society
