CE ROHS 10MM 12MM Tunable Cob Led Strip DC24V 2700k 6500K

Shenzhen Xuancai Electronic Co., Ltd
Contact Now

CE ROHS 10MM 12MM Tunable Cob Led Strip DC24V 2700k 6500K

Brand Name : XUANCAI

Model Number : Tunable Flexible Led Cob Strip

Certification : CE ROHS LM-80

Place of Origin : China

MOQ : 5 Meter/ Roll

Price : $4.5-$6.5 / Meter

Payment Terms : T/T, Western Union, Paypal , Alibaba trade assurance

Supply Ability : 100000M / Month

Delivery Time : 3-5 days

Packaging Details : 5Meter/Roll

Model : Tunable Flexible Led Cob Strip

Wattas : 10W+10W

Voltage : DC24V

CRI : >90

Color Temperature : 2700+6500K

LED Qty(LEDs/M) : 512LEDs/576LEDs

Storage Temperature : -40...+85

Working Temperature : -20...+45

Warranty : 3 Years Warranty

Spanlife : 50,000Hours

IP Rating : IP20/ IP67

PCB Width : 10MM/12MM

Contact Now

Tunable Cob Led Strip Lights 10MM/ 12MM DC24V CRI: 90 2700+6500K 10W Flexible Soft Light Strip

Product Description

Product Information
Product Model

Tunable Flexible Led Cob Strip light

FPC Width
10MM /12MM
Power
10w+10w
Voltage
DC24V

Color Temperature

2700K+6500K

LEDs/ Meter)

512Leds 576 Leds
CRI(Ra)
90

Packaging Details

5 Meter/ Roll

Product features
①Pure color: with the advantages of LED luminous components, pure light color/soft/no dazzle light.
②Flexibility: using very soft FPC substrate, can be bent greatly, easy to form, suitable for all kinds of
decoration and lighting.
③Low heat: luminous components are LED chips. The power of a single LED chip is generally less than
0.03w, and the heat of a single LED chip is very low.
④Energy saving: compared with traditional lighting and decoration, the power is reduced several times, and
the lighting effect is greatly enhanced.
⑤Environmental protection: no matter LED light source or FPC base material, all accord to ROHS standard.
⑥Safety: the led light bar uses the low voltage dc 12/24v power supply voltage.
⑦Easy to install, LED light bar with clamp, trough, iron net, etc can be installed in all kinds ofbearing surface,
in addition, due to soft and thin, also can use the double-sided adhesive to realize the function of fixed, no
need professional installation.
⑧Long service life: the normal service life of LED soft light bar is 50,000-100,000 hours, which is several
times of the life of traditional lamps.

Product characteristic parameters

Company abbrevi ation

Product si ze

(mm)

Input v oltage (V) Series- paralle l

Half a

meter powe

(W)

Half-meter shear group numbe

Emitting color CRI

Photosyn thetic efficiency level

(lm/w)

Packag e stand ard Color t oleran ce
XC 12 24 0836 P10 J18 27 90 B B2 S3

(xuancai)

500*12mm

DC24V

08-C

36-B

10W

18

2700K

>90

100-110

(Blister box)

≤3

XC 12 24 0836 P10 J18 65 90 C B2 S3

(xuancai)

500*12mm

DC24V

08-C

36-B

10W

18

6500K

>90

110-120

(Blister

box)

≤3

Reliability test standards

(A

pilot project)

(Number of test)

(Test conditions)

(Decision criteria)

(Test Vequipment)

Cold and hot shock

10pcs

-40℃/30min -- 120℃/30min, one Cycle

per hour, 100 cycles in total.

No glue crack/dead light

Cold and heat shock

chamber

The normal temperature aging

10pcs

Ambient temperature 25±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once.

1. Droop 10% or less 2.No glue crack/dead

light

Normal temperature aging block
High temperature and high humidity

10pcs

Ambient temperature 85±5℃, rated voltage /1000hr, 168H to test the photoelectric parameters once.

1. Droop 10% or less 2.No glue crack/dead light

High temperature and high humidity

aging tank

Application

CE ROHS 10MM 12MM Tunable Cob Led Strip DC24V 2700k 6500K
